SDI-12 Profile (v 1.3)
SDI-12 is a standard for interfacing data recorders with microprocessor-
based sensors. The name stands for serial/digital interface at 1200 baud.
The SDI-12 Support Group is an association of companies that produce
and use SDI-12 products with the purpose of reviewing requests to
enhance, clarify, or modify the SDI-12 architecture and that votes on
proposed changes to SDI-12.
For the complete SDI-12 standard text and information on the SDI-12
Support Group, refer to the SDI-12 web-site at the following address:
.
NOTE
SDI-12 sub modes A and B are not supported by WMT700.
NOTE
When establishing the terminal connection to WMT700, set the
following communication settings for the SDI-12 profile:
Bits per second: 1200
Data bits: 7
Parity: 1
Stop bits: 1
Flow Control: None
