Chapter 3 ________________________________________________________________ Installation
VAISALA ________________________________________________________________________ 23
Configuration and Wiring
To minimize working at height at the installation location, prepare the
transmitter configuration and wiring before climbing up.
1.
Open the six screws that hold the transmitter cover.
2.
Check that the DIP switches are set as desired. See section DIP
3.
Route the power and signal cable to the screw terminals and
connect the wires. Refer to section Wiring on page 26.
4.
Disconnect the screw terminal block by pulling it away from the
component board.
5.
Adjust the length of cable between the cable gland and the terminal
block. Make the cable short enough to close the cover without
leaving a cable loop in the transmitter.
6.
Tighten the cable gland. Leave the cover off for now.
1304-059
Figure 14
Location of DIP Switches and Screw Terminal
