Page 6 Protected Junction Box
12. Gather the RAIN, TEMP, and WIND cables and the ground wire from JP1 and secure
them to the cable tie lug using a cable tie.
When tightening the cable tie, make sure the cables are on top of the lug.
S ECURING C ABLES TO C ABLE T IE L UG
13. Gather the junction box cable and the ground wire from JP2 and secure them to the
cable tie lug using a cable tie.
When tightening the cable tie, make sure the cables are on top of the lug.
Note: Even if you are not using a ground wire at terminal JP2, secure the junction box cable to the
cable tie lug for strain relief.
14. Reattach the Protected Junction Box cover to the base.
Make sure the tabs on top of the cover snap back into their slots, locking the
cover in place.
R EATTACHING THE C OVER
