Reattach the transmitter cover to the base, Reattach the console base – DAVIS SensorLink for Weather Monitor and Wizard User Manual
Page 9
Installation
Page 9
4. Reattach the transmitter cover to the base.
Make sure the tabs on top of the cover snap back into their slots, locking the
cover in place.
5. Reattach the console base.
The closed console, with and without optional WeatherLink, is displayed
below.
A
B
SensorLink Receiver
(inside Console Base)
Power
Adapter
Weather Station
Console
110 VAC
Power Outlet
WeatherLink
(inside Console Base)
Power
Adapter
SensorLink
Receiver
WeatherLink
Connection
to Computer
110 VAC
Power Outlet
WEATHERLINK SETUP
STANDARD SETUP
