Installation Page 5
2. Remove the cover from the transmitter by pushing down on the tabs at the top until
you can remove the tabs from the slots.
3. Attach the base to the mounting surface using the #6 x 1” screws.
Use two screws (as pictured below) when attaching to a stud. Use three
screws (as pictured below) in any other case.
4. Insert the sensor cables in the appropriate jacks, as shown below.
A
B
Base
Cover
Use two screws if attaching
to a stud.
Use three screws if attaching
anywhere else.
#6 x 1" Screws
RAIN
TEMP
WIND
Rain Collector Cable
Temperature
or Temp/Humidity
Sensor Cable
Anemometer Cable
