5
Note: The orientation of the Temperature/Humidity sensor may be different from station to
station. Even if the sensor is inverted and attached to spacers it should still be removed
and replaced with the Temperature/Humidity sensor replacement kit.
3. Remove the sensor and cable clamp from the plate.
4. Return the plate to the radiation plating stack in the order it was mounted.
Insert the Temperature/Humidity Sensor
1. Locate the plate at the top of the radiation shield plating and find the
insulating disk on the underside of the plate.
2. Remove the two screws holding the insulating disk attached on the
underside and discard the disk.
3. Take the insulating disk with the mounted Temperature/Humidity sensor
and set it in the same place as the previous insulating disk.
Top Plate
Insulating Disk
