Vantage Pro® ISS Retrofit Kit

7.

Hammer the three (3) long radiation shield screws down into the base. The
screws should move fairly easily with light taps from a hammer.

8.

Remove the rain collector cone.

9.

Pull the top closed radiation shield plate off or use pliers to hold the push-
nuts while you unscrew the screws, then discard the old screws, push-nuts
and washers.

10. Save the top closed radiation shield plate for later use.

Pound the 3
long screws
down into the
base.

Twist off the rain collector cone.

Top closed
radiation
shield
plate

Remove push nuts
from the 3 long screws,
then remove the screws.
