Antenna Mast-Mount Kit
A
TTACHING
G
ROUND
P
LANE
TO
A
NTENNA
M
OUNTING
B
RACKET
Attach the antenna/ground plane to the antenna mounting bracket as shown
below. The antenna, ground plane, and hardware are provided in the antenna
installation kit.
M
OUNTING
D
IRECTLY
TO
A
W
OODEN
P
OST
Attach the antenna mounting bracket to the post using the lag screws as shown
below. Use a 3/16" (4.8 mm) drill bit to make pilot holes.
8-32 x 3/4" Screw
Flat Washer
Flat Washer
Split LockWasher
#8 Hex Nut
Ground Plane
Lag Screws
Antenna/Ground Plane
not shown for clarity.
