46
2003-2007 IN
T. VT 36
5
INSTALLATION
w w w .
D I A B L O S P O R T
. C O M
International VT 365
2003-2007
1. Find a desired location under the hood of your vehicle
to mount the DiabloSport Extreme PowerPuck. Ensure that
the location you pick is free from extreme heat, moisture,
and has sufficient room for mounting. We have found a good
place to mount the Puck is on the driver’s side.
2. Route the adjustable switch through the firewall into the
cab of your vehicle. Route the wire away from any moving
devices and away from extreme heat that may burn the wire.
Avoid cutting any factory wiring.
3. Locate your vehicle’s fuel pressure sensor. This sensor can
be found on the driver’s side of the engine block directly
behind the turbo for 2003-2004.5 trucks. You will need to
remove the Fuel Pressure Sensor inspection plate first. If your
vehicle is newer then 2004.5 the sensor can be found on the
passenger side cylinder head.
4. Unplug your vehicle’s factory harness from the fuel pressure
sensor and plug in the harness from your new
DiabloSport Extreme PowerPuck.
5. Mount the adjustable “Diablo Dial” in a convenient location
inside the cab of your vehicle.
