INSTALLATION
w w w .
D I A B L O S P O R T
. C O M
2. On the driver's side just next to the valve cover you will
find your vehicle's MAP sensor. The sensor should have a blue
weather tight seal around it. Disconnect the harness currently
plugged into your MAP sensor and plug in the
Extreme PowerPuck's harness.
3. Just in front of the MAP sensor you will find the Fuel
Pressure Sensor (FPS). As you did in step 2, disconnect the
current harness and plug in the Extreme PowerPuck's harness.
5
2003-2006 Dod
ge 5.
9L 2
4 Valve
