9. For LLY applications the Fuel
Pressure Sensor is located just below the
air intake tube on the passenger’s side of the
engine (see picture).
18
2001-2005 GM Duramax
LB7 & LL
Y 6
.6L
8. For LB7 applications the Fuel Pressure Sensor is located
just below the intercooler tube. You will need to remove
the intercooler tube itself to expose the sensor.
after plugging in the harness be sure to reconnect the tube)
10. Unplug your vehicle’s factory harness from
the fuel pressure sensor and plug in the harness
from your new DiabloSport Extreme PowerPuck.
*Please See Graphic references on next page
