INSTALLATION
w w w .
D I A B L O S P O R T
. C O M
1. Find a desired location under the hood of your vehicle
to mount the DiabloSport Extreme PowerPuck.
Ensure that the location you pick is free from extreme heat,
moisture, and has sufficient room for mounting. We have
found a good place to mount the Puck is on the driver’s side.
2. Route the adjustable switch through the firewall into the
cab of your vehicle. Route the wire away from any moving
devices and away from extreme heat that may burn the wire.
Avoid cutting any factory wiring.
3. Locate your vehicle’s fuel pressure sensor(ICP).
This sensor can be found on the driver’s side of the engine
block on the rear side of the engine.
International DT466, DT530, DT570
2004-2006
4. Unplug your vehicle’s factory harness from the fuel
pressure sensor and plug in the harness from your new
DiabloSport Extreme PowerPuck.
44
2004-2006
IN
T. DT46
6 - DT530 - DT5
70
