11. Carefully re-install the fuel valve. Be sure to tighten
the valve to 50 ft/lbs.
12. Line up the 6 bolt holes on the air horn with the 6 holes
in the gasket and re-install the air horn. After the air horn is
installed, re-connect the dipstick tube to the bracket on the
air horn.
13. Carefully re-install the EGR tube. The easiest way to do this
is to line up one side at a time and gently install the clamp
leaving it loose enough for adjustment. Once both sides are
gently clamped in place, ensure the EGR tube is in it's proper
palcement and tighten both sides.
14. On the back of the fuel rail close to the fire wall you should
see the fuel pressure sensor. After locating this sensor plug the
factory connector into the Extreme PowerPuck's harness. Plug
he other side of the Extreme PowerPuck's harness into the fuel
pressure sensor.
15. Connect the harness to your DiabloSport Extreme PowerPuck
and using the provided velcro strips mount the Extreme
PowerPuck in a convienent location.
16. Run the switch wire through the firewall and plug it into the
Extreme PowerPuck. Mount the switch in the cab where you would
have easy access while driving.
17. Drive and enjoy.
