INSTALLATION
w w w .
D I A B L O S P O R T
. C O M
5. Using the picture below as a reference, locate your vehicle’s
MAP sensor
6. Unplug your vehicle’s factory map sensor and plug in the
harness From you new DiabloSport Extreme PowerPuck into the
MAP sensor.
7. Taking the leftover connector plug it into the factory harness
8. Mount the DiabloSport Extreme PowerPuck in a safe location
Using the supplied Zip Ties/Velcro
9. Route the adjustable switch through the firewall into the
cab of your vehicle. Plug the connector into the
DiabloSport Extreme PowerPuck.
27
Cummins 8.3L Caps
