DiabloSport Extreme PowerPuck User Manual

Page 44

w w w .

D I A B L O S P O R T

. C O M

1. Inside you engine compartment you will see six steel

lines that run directly to the injectors. Next to this you

will find your Fuel Injection rail.

2005-2007 Cummins 8.3L Common Rail

INSTALLATION

Dodge Cummins 8.3L Common Rail

2005-2007

2. Once the fuel injection rail is located, find your vehicle's

fuel pressure sensor. This will be on the actual fuel injection rail.

3. Unplug you vehicle's fuel pressure sensor and plug in your

new DiabloSport Extreme PowerPuck into the sensor.

4. Plug in your vehicle's factory harness into the other side

of the DiabloSport Extreme PowerPuck's harness

5. Using the included zip ties route the cables away from

any parts which may move and become entangled.
