36
Element Name Description / Display
A Carrier 1
Parameter Sets power level and frequency of carrier signal 1:
Note: when entering this field a numeric keyboard
is displayed. A new or changed value is accepted
by pushing the Enter button (I)
B Carrier Name When entering new carrier information, the cursor
is set to this field and marked orange for editing.
The name will be stored by pushing “Enter” (I)
C Carrier 2
Parameter Sets power level and frequency of Carrier Signal 2:
Note: when entering this field a numeric keyboard
is displayed. A new or changed value is accepted
by pushing “Enter” (I)
D ALC Auto Level Control – for utmost accuracy it is
recommended to set ALC to ON (default).
For more information see chapter “System Menu”.
E Return Returns to previous site.
F IM Automatically calculates and displays the next IM
product that lies in the receiving band of the PIM31
G 123 / ABC Toggles the touch screen keyboard between
characters and numeric.
H Delete Deletes last character / character to the left of the
cursor
I Enter Entries are stored in the system when the “Enter”
button is pressed
J Keyboard Keyboard, toggles between characters and
numeric
K Space Space
L Capitals Upper case entries
Note: When using an external keyboard do not use commas in
names or descriptions. Log Data is stored in a CSV (Comma-
separated value) text form. Commas in the description will mix up
fields that are assigned for particular values, relevant e.g. when
importing data in a spreadsheet or database. The touch screen
keyboard does not offer commas for entry.
