4-60
Chapter 4 Boonton Electronics
Remote Operation 4530 Series RF Power Meter
SYSTem:COMMunicate:GPIB:ADDRess set/return instrument’s own GPIB primary address, = 0 to 30
SYSTem:COMMunicate:GPIB:LISTen set/return LISTENER line termination, = CR, LF
SYSTem:COMMunicate:GPIB:TALK set/return TALKER line termination, = NONE, CR, LF, CRLF
SYSTem:LANGuage set/return language selection, = SCPI, BOON
SYSTem:LIGHT set/return display backlight status, = ON, OFF, ON_1, ON_5
SYSTem:VERSion? return SCPI version compliance if claimed, YYYY.V as 1990.0
TRACe[1 | 2]:COUNt set/return the total number of trace pwr points to return, = 0 to 126
TRACe[1 | 2]:INDEX set/return the index of the next trace power point, = 0 to 125
TRACe[1 | 2]:DATA? return “count” trace power points in current units starting at “index”.
TRIGger:CDF:COUNt set/return the statistical mode terminal count, = 1 to 4000 million
TRIGger:CDF:DECImate set/return decimation action when reaching term cnt, = ON, OFF
TRIGger:DELay set/return trigger delay with respect to the trigger
TRIGger:HOLDoff set/return trigger holdoff, = 0 to 0.999999 seconds
TRIGger:LEVel set/return trigger level = -40 to 20dBm
TRIGger:MODe set/return trigger mode, = PKTOPK, AUTO, NORM
TRIGger:POSition set/return trigger position on display, = LEFT, MIDDLE, RIGHT
TRIGger:SLOPe set/return trigger slope, = NEGative, POSitive
TRIGger:SOURce set/return trigger source, = [see command description]
CH1 Native: Set Ch 1 to be the active channel for chan-depend talkmodes
CH2 Native: Set Ch 2 to be the active channel for chanl-depend talkmodes
TALKMODE? Native: return active channel and current talkmode mnemonic
TKERR Native: return next queued error code number, 0 = no error
TKERRMSG Native: return next queued error code number and description
TKSDATA Native: return sensor data page from sensor’s eeprom
TKSSLOW Native: return slow freq calfactor table page from sensor EEPROM
TKSFAST Native: return fast freq calfactor table page from sensor EEPROM
TKSCWRG Native: return CW linearity factor table from sensor EEPROM
TKSMSG Native: return message page from sensor EEPPROM
TKAVG Native talkmode: return current average reading for active channel
TKPWR Native talkmode: return current power array for active channel
TKBOTH Native talkmode: return current average reading for both channels
TKMK1 Native talkmode: return current reading at Marker1 for active channel
TKMK2 Native talkmode: return current reading at Marker2 for active channel
TKPLSPWR Native talkmode: return current automatic pulse pwr meas for act chan
TKPLSTIM Native talkmode: return current automatic pls timing meas for act chan
TKMKMEAS Native talkmode: return current marker measurements for act chan
TKSMEAS Native talkmode: return array of statistical meas for active channel
Table 4-1 Remote Command Summary (Cont)
