4-58
Chapter 4 Boonton Electronics
Remote Operation 4530 Series RF Power Meter
MEMory:SYS[1 | 2 | 3 | 4]:LOAD recall stored instrument setup from setup memory location 1 thru 4.
MEMory:SYS[1 | 2 | 3 | 4]:STORe store instrument setup in setup memory location 1 thru 4.
MEMory:FDOFfset:TBLA:DATA set/return data array for frequency-dependent offset table A
MEMory:FDOFfset:TBLB:DATA set/return data array for frequency-dependent offset table B
OUTPut:{INTernal | EXTernal}:SIGNal set/return selected calibrator output state, = OFF, ON
OUTPut:{INTernal | EXTernal}:LEVel set/return selected calibrator output level, = -60.0 to +20.0 dBm
OUTPut:EXTernal:MODulation set/return external calibrator modulation, = CW, PULSE
OUTPut:EXTernal:PULse:PERiod set/return external calibrator pulse period, = .1, 1, 10 ms
OUTPut:EXTernal:PULse:DCYC set/return external calibrator pulse duty cycle, = 10 to 90 %
OUTPut:EXTernal:PULse:SOURce set/return external calibrator modulation source, = INT, EXT
OUTPut:RECOrder:SIGNal set/return Recorder Output state, = OFF, ON
OUTPut:RECOrder:SOURce set/return Recorder Output source, = CH1, CH2
OUTPut:RECOrder:MEAS set/return Recorder function, = AUTO, MANUAL, ALARM
OUTPut:RECOrder:POLarity set/return Recorder Output polarity, = UNIPOLAR, BIPOLAR
OUTPut:RECOrder:MIN set/return Recorder Output dnscale level, = -100.00 to +100.00 dBm
OUTPut:RECOrder:MAX set/return Recorder Output fullscale level, = -100.00 to +100.00 dBm
OUTPut:RECOrder:FORCE set/return Recorder Output level directly, = -10.0 to +10.0 volts
OUTPut:RECOrder:CALibration:SLOPe set/return Recorder Output slope adjustment, = -10.00 to +10.00%
OUTPut:RECOrder:CALibration:ZERO set/return Recorder Output zero adjustment, = -1.000 to +1.000 volts
OUTPut:RECOrder:CALibration:SAVE save Recorder Output adjustments to non-volatile calibration memory
READ[1 | 2]:CW:POWer? perform measurement, return new average reading in power units
READ[1 | 2]:CW:VOLTage? perform measurement, return new average reading in voltage units
READ[1 | 2]:MARKer[1 | 2]:POWer? perform measurement, return reading at the specified marker
READ[1 | 2]:ARRay:MARKer:POWer? perform measurement, return readings at both markers
READ[1 | 2]:ARRay:MARKer:PERcent? perform measurement, return statistical percent at both markers
READ[1 | 2]:ARRay:CW:POWer? perform measurement, return array of power readings
READ[1 | 2]:ARRay:CW:VOLTage? perform measurement, return array of voltage readings
READ[1 | 2]:ARRay:PULse:POWer? perform measurement, return array of marker measurements
READ[1 | 2]:ARRay:AMEAsure:TIMe? perform measurement, return array of automatic pulse timing measrmnts
READ[1 | 2]:ARRay:AMEAsure:POWer? perform measurement, return array of automatic pulse pwr measurmnts
SENSe[1 | 2]:AVERage set/return trace averaging count, = 1 to 4096
SENSe[1 | 2]:BANDwidth set/return sensor video bandwidth, = LOW, HIGH
SENSe[1 | 2]:CORRection:OFFset set/return sensor offset value in dB, = -100.00 to +100.00 dB
SENSe[1 | 2]:CORRection:FREQuency set/return sensor measurement frequency in GHz, = 0.001 to 110.00
SENSe[1 | 2]:CORRection:CALFactor set/return sensor cal factor in dB, = -3.00 to +3.00 dB
SENSe[1 | 2]:CORRection:FDOFfset set/return current freq dependent offset table, = OFF, TBLA, TBLB
SENSe[1 | 2]:CORRection:TEMPComp set/return peak sensor temperature compensation state, = OFF, ON
SENSe[1 | 2]:FILTer:STATe set/return filter state, = OFF, ON, AUTO
SENSe[1 | 2]:FILTer:TIMe set/return filter time, = 0.01 to 15.00 seconds
SENSe[1 | 2]:IMPEDance set/return voltage probe sensor impedance for power calculations
Table 4-1 Remote Command Summary (Cont)
