MN179-1 _ 02/14 AirSep Corp. - FreeStyle 5 Service Manual Rev B
1.4 FreeStyle 5 Specifications
Oxygen
Concentration:* 1-5 pulse settings; equivalent to a continuous flow of 90% oxygen +5.5 / -3%
Flow Rate Settings: 1 ,2, 3, 4 & 5 LPM (equivalent to continuous flow)
Setting 1±15%. Settings 2 through 5±10%
Dimensions:
10.7 in. high x 6.6 in. wide x 4.4 in. deep (27.2 cm high x 16.8 cm wide x 11.2
cm deep)
Weight: 6.2 lb (2.8 kg); 1.8 lb (.8 kg) optional AirBelt
Power:
AC Power Supply: Input: 100-240VAC, 50-60Hz, 2A | Output: 15V
DC Power Supply: Input: 12VDC-24VDC, 15A max | Output: 15V, 8A max
Battery duration
(Rechargeable
lithium Battery) 5 LPM – 1 hour; 4 LPM – 1 hour, 15 minutes; 3 LPM – 1 hour, 30 minutes; 2
LPM – 2 hours; 1 LPM – 3 hours
Optional AirBelt when combined with the internal battery:
5 LPM – 2 hours, 30 minutes; 4 LPM – 3 hours; 3 LPM – 3 hours, 30
minutes; 2 LPM – 4 hours, 30 minutes; 1 LPM – 7
hours
Battery recharge
time:
3 hours, 15 minutes; optional AirBelt: 3 hours, 30 minutes
Initial startup time 2 minutes
Battery cycle life:
Approximately 300 cycles, then 80% capacity or below.
Audible alarms and
pulse visual
indicators: Start-up – audible and visual (GREEN indicator light);
Pulse flow – visual (GREEN indicator light);
Battery condition – battery level (GREEN indicator lights);
Battery Low – audible and visual (YELLOW alarm light);
Battery shutdown – audible and visual (YELLOW alarm light);
Cannula disconnect- audible and visual (YELLOW alarm light);
System overdraw – audible and visual (YELLOW alarm light);
General malfunction – audible and visual (RED alarm light).
**Temperature
range: Operational temperature: 41°F to 104°F (5°C to 40°C)
(Up to 95% RH (non-condensing)
Storage temperature:
-4°F to 140°F (-20°C to 60°C)
**Max Operational
Altitude: up to 12,000 ft (3,657.6 m) (483mmHg) Higher altitudes may affect
performance
* Based on an atmospheric pressure of 14.7 psi (101 kPa) at 70°F (21°C)
** Operating outside of these specifications can limit the concentrator’s ability to meet Oxygen Concentration specifications at higher liter flow
rates.
