SMS Mobile Sensor Configuration and Logging Options
Revision 8/1/2013
© 2013 Ag Leader Technology, Inc All Rights Reserved 14
Connecting a GreenSeeker RT100/500/505 Sensor
to SMS Mobile
[Back to Top]
1. Connect the GreenSeeker Sensor to the Mesa, PC or handheld
device with the serial cable (supplied with the GreenSeeker
unit) to the 9-pin serial port. If using the 505 model you will
need to connect the GreenSeeker Sensor to a null modem
cable (Ag Leader Part Number: 200819) with a gender adapter
(available at any electronics store) between the null modem
and PC cable.
Photo courtesy of GreenSeeker
2. Open the SMS Mobile Software.
3. Tap the Setup menu and then the Sensors icon.
4. In the Available Sensor Configurations window tap Add.
5. Select the GreenSeeker RT100/500/505 from the Sensor Model drop down menu.
