ISO Serial Bridge Module
DirectCommand Sprayer
Quick Reference Guide
AL: 2006007 - ENG Rev A
Create Configuration
Start of Configuration Wizard
Application
Note: Controller Make and Model need to be selected as
Ag Leader and ISO Serial Bridge.
Select Operating Configuraiton
Create Event
Chem 1
10.00
10.00
Rate 1 and Rate 2
allows operator to set desired target rates
Increment
values when using up and down arrows in the Product
Control Toolbox
Prescription
press to load a map-based prescription file
Rate 1: Rate 2: Increment:
0.00
Rate Control Settings
0.00
Rate Control Containers
MAP (lb)
Enter Target Rate and Increment
Runscreen>Product Tab>Wrench>Input Target Rate 1>Input Increment
Note: Some controllers allow users to increase the target rate by an increment amount of their own.
The ISO Serial Bridge module will not know that the Target Rate has changed and may trigger a Rate
Not Responding Alarm. To avoid this, use the increment increase/decrease function within the Ag
Leader Display.
Minimum Flow: Rx
0.00 0.00
