1
ISO Serial Bridge Module
DirectCommand Sprayer
Quick Reference Guide
AL: 2006007 - ENG Rev A
Virtual Terminal Quick Reference Guide (PN 2006300) may also be referenced when troubleshooting
problems.
Status Bar Appears while Object Pool is in the
process of loading.
Enable Virtual Terminal and Task Controller
VT button appears in task bar once button is checked.
ISOBUS Settings
Enable Virtual Terminal
Enable Task Controller
Task Controller
Virtual Teminal
Supported on compatible equipment ECUs.
Enable Virtual Terminal
Broadcast GPS Speed
Auxiliary Module Support
Function Instance Function Instance
Enable Task Controller
Virtual Terminal Task Controller
ISOBUS Settings
0 0
Setup a Configuration within the Virtual Terminal
Select System Type Select Controller Make and Model
A B
