DirectCommand TM
Strip Till / Air Cart
Quick Reference Guide
AL: 2006315 - ENG Rev B
Bin Full
press to fill
container
Bin Partially Filled
press to specify
container amount
Bin Empty
press to empty
container
Tank Alarm
Setting
can set % remain-
ing or amount
remaining for low
container alarm
To access the Rate
Control Settings window:
Rate 1
Rate Control Settings
1.5 ft 3
10 %
Rate 2 Increment
200 150 1
Minimum Flow
0.00 lb/min
DAP (lb)
Rate 1 Rate 2 Increment
250 300 1
Minimum Flow
0.00 lb/min
Potash (lb)
Rate 1 Rate 2 Increment
20 30 1
Minimum Flow
0.00 lb/min
Sulfur (lb)
Rx
Rx
Rx
Rate Control Containers
Rate Control Settings
Rate Control Containers
Full: 100 ft 3
Current: 100 ft 3
10 ft 3
10 %
Bin 2 - Potash
Full: 15 ft 3
Current: 15 ft 3
1.5 ft 3
10 %
Bin 3 - Sulfur
Rate 1 and Rate 2
allows operator to set
desired target rates
Increment
values used when using
up and down arrows in the
Product Control Toolbox
Rx
press to load a map-based
prescription file
DAP
250
250
Application Configuration
Full: 100 ft 3
Current: 100 ft 3
10 ft 3
10 %
Bin 2 - DAP
