5
Display Quick Reference
Guide
Quick Reference Guide
2005979-ENG Rev F / AF:602-0300-01-E
System Features
• Sunlight-readable Screen
• Rugged sealed enclosure
• Compatible with most NMEA GPS receivers
• DirectCommand and SeedCommand Product
Control using Industry-Standard CAN Bus
interface
• Adjustable volume control
• Perspective 3D View Map
• Report Preview
• Automatic Field Selection
• Automatic Module Firmware Upgrade
• Advanced GPS Diagnostics
• USB media slot
• 28-pin plug compatible with other Ag Leader
displays.
• RAM mount
System Uses
• Manual Guidance
• ParaDyme™, GeoSteer™ and OnTrac3
automated steering
• Planter DownForce Control
• Norac UC5
• Video Camera Inputs
• Mapping Tillage Operations
• Mapping and Logging Product Applications
• Mapping of all field boundaries, sub-boundaries,
waterways and terraces
• Grain Yield Monitoring
• Variety Logging
• Granular and Liquid Fertilizer Application
• Liquid Spray System Control
• NH3 Application Control
• Application Control of Multiple Bin Spinner
Spreaders
USB Flash Drive
A USB Flash Drive can be used to save and
transfer data in and out of the display.
Technical Specifications
Do not exceed the specifications below:
• Storage Temperature:
-4° to +176°F (-20° to +80°C)
• Operating Temperature:
14° to +156°F (-10° to +70°C)
• Operating Input Voltage: 9 –16 V DC
• Max Current Rating: 4.0 amp
• Environmental Protection Rating: IP64
• No Protective Grounding required
• Use 150V minimum insulation rating for external
circuits
Color Touch Screen
The display features a color touch screen display.
The touch screen allows easy and intuitive
navigation through the screens on the display
without the need for any external keypad or
mouse devices. Here are a few key things
to remember if you are new to using a touch
screen device:
• Do not use any sharp objects for running
the touch screen device, this could result in
damage to the display. Using the tip of a finger
is the recommended method of operating the
display touch screen.
• Do not use any harsh chemicals to clean the
touch screen. Using a damp soft cloth or an
anti-static wipe made specifically for cleaning
computer displays is the correct way to clean
the screen and the enclosure.
• The touch screen requires only a gentle touch
of about half-second in duration to operate
correctly. A common mistake is to try to
navigate too quickly through the system using
firm taps instead of gentle presses.
Attaching the Display
Mount the display to a secure support inside
the vehicle cab taking the following into
consideration:
• The display must be readily accessible to the
machine operator
• The display must not obstruct the operator’s
normal driving view nor interfere with existing
machine controls
