Display Quick Reference
Guide
Quick Reference Guide
2005979-ENG Rev F / AF:602-0300-01-E
Connecting the Systems
Display System
P
ara
D
yme
System
(Roof Module = IP65)
Mounting
Brackets
Fuse Type
Blade Style (ATO/ATC)
5 A rating
15 A rating
Operating Voltage
9-16 V DC
Max Current Rating
Ag Leader Integra 4.0 A
Versa 2.5 A
ParaDyme/GeoSteer 10 A
G
eo
S
teer
System
(GCU = IP66)
Display System Display System
OnTrac3 System Display System
