DirectCommand
TM
Sprayer
Quick Reference Guide
AL: 2006310 - ENG Rev B
Actual Rate
actual rate of product being applied as determined
by the flow sensor
Product in Tank
Target Rate
desired amount of product to apply
Target Rate #1 & #2
preset application rates that allow a quick change between rates
Manual Valve Control
allows operator manual control of valve
Prescription
allows rates to be determined by a loaded prescription
Up and Down Arrows
allow rates to be adjusted manually
Settings button
opens Rate Control Settings screen (explained on next page)
To change values shown on Product Tab and in Product Control
Toolbox, go to the next page where the Rate Control Settings
screen is explained.
Product Control Toolbox
To view run screen:
To start the Field Operation Wizard and load a configuration:
Configuration
Start Field Operation
Chem 1 gal/ac
10.00
10.00
1
20
10
2
Flow:
Container: 24.2 gal/min
589 gal
80 ft 0 in 100%
