Part No. 2002831-32 Rev. B 2
Flow Meter Configuration for a single product (continued)
STEPS ACTION
6 Select Implement
Select an existing Implement from the Implement List. If a new Implement
needs to be created, press the New button to launch the Implement Setup
Wizard.
7 Select Implement Attachment Method
The Implement Setup Wizard appears. Use the drop-down list to select an
implement attachment method: Rear Drawbar, Rear 3-Point Hitch, Front
Drawbar or Front 3-Point Hitch. Press Next to continue.
Note: Spinner Spreader users should check the Spinner Spreader Implement
Type check box, press Next and proceed to Step 11.
8 Enter Full Swath Width
Enter the full width of the spray boom expressed in feet (or meters for metric
applications). Press Next to continue.
9 Enter Number of Boom Sections
Use the up and down arrow buttons to enter the total number of boom sections.
Press Next to continue.
10 Enter Boom Section Widths from Left to Right
The system automatically divides the boom into equal length sections. Select
individual sections and use the on-screen keypad to edit boom section lengths if
needed. Press Next to continue.
11 Enter Distance from Hitch to Application Point
Use the numeric keypad to enter the distance from the hitch to the application
point. Press Next to continue.
12 Enter Implement Name
Use the keyboard button to enter a name for the implement. Press the Finish
button to complete the implement setup process and continue with the Operating
Configuration Wizard.
13 Select Operating Mode
Use the drop-down list to select Rate Logging/Control. Press Next to continue.
14 Select Controller
Use the drop-down list to select the desired controller. If the controller you wish
to use is not in the list, press New.
