Part No. 2002831-31 Rev. B 8
Section 7: AutoSwath Sensitivity
Settings
The AutoSwath feature automatically increases or decreases the logged width of the
tillage equipment, according to your field's boundaries and previously-tilled areas. The
AutoSwath feature includes sensitivity levels, which compensate for varying degrees of
GPS performance. To change sensitivity levels, select the Configuration Tab, and press
the AutoSwath Settings button. These sensitivity settings are specific to that
combination of Vehicle and Implement.
If swath adjustments are performing inaccurately, adjust the sensitivity accordingly.
Sensitivity 3 is the default setting. Other settings include:
Note: You must have an unlock code to activate the AutoSwath feature. If you have been
using AutoSwath with the DirectCommand™ system, the feature is already activated and ready to
use. If you have not unlocked the AutoSwath feature yet, the code can be purchased through your
local Ag Leader dealer.
Setting Purpose
Sensitivity 5 Use with RTK or DGPS sub-meter, terrain-compensated GPS.
Sensitivity 4
Use with RTK or DGPS sub-meter GPS. Terrain compensation
recommended.
Sensitivity 3 Use with sub-meter accurate GPS.
Sensitivity 2 Use with 1+ meter accurate GPS.
Sensitivity 1
Swath segments are all on or all off. Use with 1+ meter accurate
GPS.
