Part No. 2002831-31 Rev. B 2
Tillage Configuration (continued)
STEPS ACTION
9 Enter Implement Name
Use the keyboard button to enter a name for the implement. Press Finish to return to
the Operating Configuration Wizard.
10 Select Implement Switch Polarity
If you will be using an implement switch, choose standard or reversed polarity. If an
implement switch is not in use, select None. Press Next to continue.
Note: Set to None if there is not an implement switch connected to shut off logging
when the implement is raised. This setting can be changed under Configuration
Settings.
11 Select Ground Speed Source
Select your ground speed source. If you will be using GPS as the primary you will
need to select a secondary source. Press Next to continue.
12 Edit Configuration Name
Use the keyboard button to edit the suggested configuration name. Press Finish to
complete the configuration process.
