Component identification 9

Rear panel LEDs and buttons

Item

Description

Status

1

NIC link LED

Solid green = Link exists

Off = No link exists

2

NIC status LED

Solid green = Link to network
Flashing green (1 Hz/cycle per sec) = Network

active

Off = No network activity

System board components
