Hardware options installation 50

Item Description

Definition

12800 = 1600-MT/s

10600 = 1333-MT/s
8500 = 1066-MT/s

6

DIMM type

R = RDIMM (registered)

E = UDIMM (unbuffered with ECC)

L = LRDIMM (load reduced)

For the latest supported memory information, see the QuickSpecs on the HP website

(

http://www.hp.com/go/qs

). At the website, choose the geographic region, and then locate the product by

name or product category.

Single-rank and dual-rank DIMMs

DIMM configuration requirements are based on these classifications:

Single-rank DIMM—One set of memory chips that is accessed while writing to or reading from the

memory.

Dual-rank DIMM—Two single-rank DIMMs on the same module, with only one rank accessible at a time.

The server memory control subsystem selects the proper rank within the DIMM when writing to or reading
from the DIMM.
Dual-rank DIMMs provide the greatest capacity with the existing memory technology. For example, if current

DRAM technology supports 2-GB single-rank DIMMs, a dual-rank DIMM would be 4 GB.

Memory subsystem architecture

The memory subsystem in this server is divided into channels. The processor supports two channels, and each

channel supports a DIMM slot.

Channel

Population order

Slot number

1

A

1

2

B

2

DIMM slots are identified by number and by letter. Letters identify the population order. Slot numbers are

reported by ROM messages during boot and are used for error reporting. For the DIMM slot locations, see

"DIMM slot locations (on page

11

)."

ECC memory

The server supports the standard ECC memory correction mode. Standard ECC can correct single-bit memory

errors and detect multibit memory errors. When multibit errors are detected, the error is signaled to the server
and causes the server to halt.

General DIMM slot population guidelines

The server supports a maximum of 16 GB memory using two 8 GB single-rank or dual-rank UDIMMs.

The server supports up to 1600 MT/s ECC UDIMMs.
