Setup 37

6.

Connect an Ethernet cable to the server NIC 1/shared iLO connector, and then connect the cable to any

switch network port.

Complete the switch setup

After the Ethernet cable connection is made, check the network LED status on both the server and the switch

to confirm successful connection:

In the server front panel, the NIC status LED

—Solid green

In the switch, the Link/Act LED on the network connector used—Initially, solid green to indicate
successful connection, and then flashing green to indicate active communication with the network.
