Hardware options installation 38

Hardware options installation

Introduction

If more than one option is being installed, read the installation instructions for all the hardware options and
identify similar steps to streamline the installation process.

WARNING:

To reduce the risk of personal injury from hot surfaces, allow the drives and the

internal system components to cool before touching them.

CAUTION:

To prevent damage to electrical components, properly ground the server before

beginning any installation procedure. Improper grounding can cause electrostatic discharge.

Bezel faceplate

Use the interchangeable, colored bezel faceplates in this option kit to customize the look of your server.

Decorative purpose—Choose the faceplate color that complements your office environment.

Functional purpose—In a multiserver office, use different colored faceplates to identify a server unit,
based on the assigned function.

For more information about product features, specifications, options, configurations, and compatibility, see
the product QuickSpecs on the HP website (

http://www.hp.com/go/qs

).

To install the component:
Perform steps 1 to 3 only if the front bezel is secured from inside the chassis.

1.

Power down the server (on page

15

).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the front bezel (on page

17

).

5.

Remove the screws securing the bezel frame to the attached bezel faceplate.
