Chapter 4 Accessories
26
required for a board spans two or more blocks shown on the screen,
reserve all blocks required by the board. If the memory range required for
the board is less than one block, select the whole block that contains the
range.
NOTE Boards may share a reserved memory block as long as each
board uses a unique memory address range within the block.
No two boards may use the same memory address range.
Reserve memory blocks for all remaining ISA non-plug-and-play boards
you are installing.
8. Press the Escape key to return to the ISA Non-Plug-and-Play Boards
menu.
9. Use the down arrow key to select the DMA Resources option from the
menu, and press the Enter key.
10. Use the up and down keys to select the DMA channel that corresponds to
the DMA channel required for the ISA board you are installing, and press
the [F7] or [F8] function key to reserve that DMA channel. Reserve all
DMA channels needed for the board.
NOTE Each board must use unique DMA channel(s). No two boards
may use the same DMA channel(s).
Reserve DMA channels for all remaining ISA non-plug-and-play boards
you are installing.
11. Press the Escape key to return to the ISA Non-Plug-and-Play Boards
menu.
12. Use the down arrow key to select the I/O Port Resources option from the
menu, and press the Enter key.
13. Use the up and down keys to select the I/O port block that corresponds to
the I/O port range required by the board you are installing, and press the
[F7] or [F8] function key to reserve that block. If the I/O port range
required for the board spans two or more blocks shown on the screen,
reserve all blocks required by the board. If the I/O port range required for
the board is less than one block, select the whole block that contains the
range.
