Chapter 1 Installation Overview
4
Cooling Duct/Cover
Hook
Fan Cable
Power Supply Harness
Figure 1-2. Removing the Cooling Duct/Cover
Install Additional Memory
Use HP SIMMs listed on the Technical Reference Card, located in the pouch on
the side of the chassis.
CAUTION Wear a wrist strap and use a static-dissipating work surface
connected to the chassis when handling components.
1. Align the notched corner on the SIMM with the key on the end of the slot
and insert the SIMM at a 45-degree angle, as shown in Figure 1-3.
2. Pivot the SIMM to the 90-degree angle until the retaining clips on both
sides snap into place.
3. If the cooling duct/cover was removed, replace it before replacing the
NetServer cover.
