Operations 21
The air baffle slides down to a closed position.
Remove the PCI riser cage
CAUTION: To prevent damage to the server or expansion boards, power down the server and
remove all AC power cords before removing or installing the PCI riser board assembly.
1. Power down the server (on page 16 ).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
o Extend the server from the rack (on page 17 ).
o Remove the server from the rack (on page 16 ).
4. Remove the access panel (on page 19 ).
5. Remove the processor air baffle (on page 20 ).
6. Disconnect all cables connected to any existing expansion boards.
7. Remove the PCI riser cage:
a. Unfasten the three screws in the PCI riser cage.
