The reserved volume for BC/SS and BC Z. Only LDEVs that are allocated to each user are shown.
Description Item
Reserved volume LDEV's identifier. Click to open the LDEV property window LDEV ID
Reserved volume LDEV's name LDEV Name
Reserved volume's emulation type Emulation Type
Reserved volume's capacity Capacity
Displays number of paths to reserved volume Number of Paths
Displays Add Reserve Volumes window Add Reserve Volumes
Displays Remove Reserve Volumes window Remove Reserve Volumes
Click to open a dialog for downloading table information to a file. Export
Consistency Groups tab
Description Item
The consistency group identification number. CTG ID
Click to open the Consistency Group Properties window.
The status of consistency group. Status
•
BC Used: Consistency group used by BC/SS.
•
BC Used (RAID Manager) Z: Consistency group used for BC Z pairs and
managed with RAID Manager.
•
BC Used (PPRC/BCM) Z: Consistency group used for BC Z pairs and managed
with PPRC or Business Continuity Manager.
•
FS Used: Consistency group used for FS pairs.
• SS Used: Consistency group used for SS pairs.
•
Mainframe Reserved: Consistency group reserved for use with PPRC or
Business Continuity Manager.
