A RAID Manager command reference
This topic describes RAID Manager commands corresponding to actions in the RWC GUI.
Statuses required for RAID Manager tasks
You can use RAID Manager to perform pair tasks. You can also use RWC. To perform tasks using
RAID Manager, you run existing commands for pair tasks or the raidcom commands. Use raidcom
commands to store 65 or more snapshot data or use 64 or more MU numbers. You can use the
existing commands for pair tasks only for the pairs which have 0 to 63 MU numbers.
The following table shows the RAID Manager existing commands and raidcom commands you
can use to perform pair tasks, as well as the RWC tasks.
RWC task RAID Manager command Pair task
Create pairs (using the Create Pair
wizard) paircreate Create pair
raidcom add snapshot
Split pairs (using the Split Pairs wizard) paircreate –split Create and split pair
Split pairs (using the Split Pairs wizard) pairsplit Split pair
raidcom modify snapshot -snapshot_data
create
raidcom modify snapshot -snapshot_data
split
Resynchronize pairs (using the Resync
Pairs wizard) pairresync Normal copy
raidcom modify snapshot -snapshot_data
resync
Resynchronize pairs (using the Resync
Pairs wizard) pairresync -restore Reverse copy
raidcom modify snapshot -snapshot_data
restore
Delete pairs (using the Delete Pairs
window) pairsplit -S Delete pair
raidcom delete snapshot
RAID Manager pair status names
Running a command for a pair with a different status than the one required can give you mixed
results.
The following table shows results for tasks run with statuses other than those that are required.
RAID Manager command Status
pairsplit -E pairsplit -S pairresync
-restore pairresync pairsplit paircreate
-split paircreate
Ab Np Ab Ab Ab Ab Ok SMPL
Ab Ab Np Np Ab Ab Np COPY
Ab Ok Np Np Ok Ok Np PAIR/PFUL
Ab Ok Ok Ok Np Np Ab PSUS/PFUS
Ab Ab Np Np Ab Ab Np RCPY
72 RAID Manager command reference
