Description Item
Number of differential tables in use. The number of differential tables is not
increased or decreased by FS pair tasks because differential tables are not used
for FS pairs. Number of Differential Tables
Click to open the View History window. View Histories button
Replica LDEVs tab
Only pairs that consist of the P-VOL and S-VOLs (the source and target volumes for FC Z or FCSE)
allocated to each user are shown.
Description Item
Selected LDEV's identifier. LDEV ID
Selected LDEV's name. LDEV Name
Selected LDEV's emulation type. Emulation Type
Selected LDEV's capacity. Capacity
The copy type and volume. Copy Type
Values:
•
BC-L1: BC/SS first cascade layer (L1) pair
•
BC-L2: BC/SS second cascade layer (L2) pair
• FS: FS pair
•
SS: SS pair
• BC Z: BC Z pair
•
FC Z: Compatible FlashCopy relationship
•
FCSE: Compatible FlashCopy SE relationship
Status of BC, FS, SS, and BC Z volumes:
• Primary: P-VOL
•
Secondary: S-VOL
Status of FC Z and FCSE volumes:
S means a source volume. T means a target volume.
• S-Normal: Source volume in the normal status
•
T-Normal: Target volume in the normal status
•
ST-Normal: Normal volume which is set for the source volume and the target
volume
•
S-Failed, S-Full, S-Full & Failed: Source volume in the abnormal status
•
T-Failed, T-Full, T-Full & Failed: Target volume in the abnormal status
• ST-Failed, ST-full, ST-full & Failed: Abnormal volume which is set for the source
volume and the target volume
Click to open a dialog for downloading table information to a file. Export button
Local Replications window
The following image shows this window.
Local Replications window 81
