LDEV menu
Settings menu

Array menu

The Array menu appears after you start XPWatch. This menu lists all the arrays that are connected to
the host.

The Array menu also displays the XPWatch version. You can also view the XPWatch version using
the following command in the command prompt:

XPWatch.exe -v

Figure 6

shows the screen that displays the XPWatch version.

Figure 6 XPWatch version

.

To select an array, enter the number (Num) corresponding to it. For example, to select the 10055
array, enter 1.

NOTE:

You can select only one array at a time.

Figure 7

shows the Array menu.

Figure 7 Array menu

.

Table 6

lists the fields of the Array menu.

Table 6 Array menu — fields

Description

Screen field

Selection number

Num

Serial number of the array

Serial

Type of the array

Type

XPWatch and XPSketch Reference Guide

19
