3 - 1
Understanding the
Console
The Server Image Copy console is the user interface that manages,
monitors, and controls your full-server protection solutions. On the left are static navigation buttons
which initiate workflows and display monitoring pages. In essence, these navigation buttons control
what is displayed in the main window. When viewing the Monitor page, the main window is divided
into two sections. The top pane displays overview monitoring information. The bottom pane displays
detailed data. You can hide the details pane by clicking on the Hide details text. You can display the
details pane by clicking on the Show details text.
Each time you open the Server Image Copy console, it will automatically open to the Monitor page.
Any existing jobs will be displayed. If there are no existing jobs, the display will be blank.

Source protection—If you want to protect a source, see Setting Up Source Protection on
page 4-1.

Import job—If you want to import an existing job, see Importing a Job on page 5-1.

Monitoring jobs—For details on the controls and statistics on the monitoring page, see
Monitoring Jobs on page 6-1.

Recovery to an existing physical or virtual machine —If you want to recover a source to an
existing physical or virtual machine, see Recovering to an Existing Machine on page 7-1.

Recovery to an automatically provisioned virtual machine —If you want to recover a source
to an automatically provisioned virtual machine, see Recovering to an Automatically
Provisioned Virtual Machine on page 8-1.
NOTE: The Server Image Copy console requires a 1024x768 minimum screen resolution.
