Component identification 21
Green LED Amber LED Interpretation
Flashing (2 Hz)
Alternating with
amber LED
Flashing (2 Hz)
Alternating with
green LED
One of the following conditions exists:
• The charging process has timed out.
• The capacitor pack is not connected.
On On The flash code image failed to load.
Off Off The flash code is corrupt.
Power supply backplane connectors
Item Description
BP1 Drive bay 1 power cable
BP2 Drive bay 2 power cable
BP3 Drive bay 3 power cable
P1
Power supply 1 cable
P2 Power supply 2 cable
P6 SATA power cable
P7 SATA power cable
P8 SATA power cable
P9 Video adapter power cable
P10 Data cable
P12 Video adapter power cable
Drive cage jumper configuration settings
Drive cage Installation Pin setting
1 Standard No jumper
2
Optional 1-2*
3 Optional 2-3
*Optional drive cages ship with the jumper set across pins 1 and 2.
