Virtual Connect server profiles 178
Column name Description
If the speed type is "Preferred", the speed of the network is the same as the
preferred speed of the network to which the connection is associated. If no
preferred speed is configured for a network, it defaults to "Auto".
If the speed type is "Custom", the user can configure any speed from 100Mb
to MAX Configured speed for the network in 100-Mb increments.*
Allocated Port Speed Allocated bandwidth of the port. See "Bandwidth assignment (on page
146 )."
Boot Setting Enables or disables offload or boot on the network connection. Valid values
are DISABLED, PRIMARY, (SECONDARY), and USE-BIOS. For more
information, see "Creating iSCSI connections (on page 161 )." After selecting
an option, you must click outside the grid to complete the selection. This is the
same procedure that is followed when selecting a fabric or network for an FC
or Ethernet connection, respectively. Once the Boot Setting column has been
completed, you can then edit the Target Port Name and LUN.
MAC As of VC 3.70, the actual hardware MAC for mapped connections appears.
For unmapped connections, FACTORY-DEFAULT continues to appear. If the
profile is assigned, the MAC address assigned to the port appears. If the
profile is unassigned and the domain is set to show factory default MAC
addresses, FACTORY-DEFAULT appears. If the profile is using VC-defined
MAC addresses, the VC-defined MAC address appears. If the profile is using
hardware MAC addresses, FACTORY-DEFAULT appears.
Mapping Server hardware mapping assignment. See "iSCSI and FCoE port
assignments (on page
144 )."
Action Delete a connection. Connections can be removed starting with the last
connection in the list.
FC HBA Connections
Port Relative order of the Fibre Channel port on the server receiving the profile
Connected to Bay number of the VC-FC module to which the port is connected
FC SAN Name
Name of the SAN fabric to which the port is connected, or Unassigned
Status Status of the Fibre Channel module
Port Speed Type Speed of the VC-FC module port connected to the port
WWN As of VC 3.70, the actual hardware MAC for mapped connections appears.
For unmapped connections, FACTORY-DEFAULT continues to appear. If the
profile is assigned, the WWN assigned to the port appears. If the profile is
unassigned and the domain is set to show factory default WWNs,
FACTORY-DEFAULT appears. If the profile is using VC-defined WWNs, the
VC-defined WWN appears. If the profile is using hardware WWNs,
FACTORY-DEFAULT appears.
Action Delete a connection. Connections can be removed starting with the last
connection in the list.
FCoE HBA Connections
Port Relative order of the FCoE port on the server receiving the profile
Connected to Bay number of the VC module to which the port is connected
FC SAN Name Name of the SAN fabric to which the port is connected, or Unassigned
Status Status of the VC module
Port Speed Type Speed of the VC module port connected to the port
Allocated Port Speed Allocated bandwidth of the port. See "Bandwidth assignment (on page
146 )."
WWN As of VC 3.70, the actual hardware MAC for mapped connections appears.
