Virtual Connect server profiles 146
Device Port Type VC Connections Assigned
2 NC551m Enet 4, FCoE 4, Enet 10
MEZ2 1 NC551m Enet 5, iSCSI 1
2 NC551m Enet 6, iSCSI (PF disabled)
Bandwidth assignment
In Flex-10 environments, four FlexNICs must share a single 10Gb link. Each FlexNIC is allocated a portion
of that 10Gb link's bandwidth. The bandwidth assigned to the four FlexNICs in a single physical port cannot
exceed 10Gb, but the requested bandwidth settings you specified in the profile might exceed 10Gb.
Each FlexNIC is assigned a bandwidth value that is a portion of a 10Gb link. A 10Gb NIC might not be able
to saturate a 10Gb link, so FlexNIC bandwidth is limited to a proportion of the NIC's actual throughput. For
example, a FlexNIC that is assigned a requested bandwidth value of 5Gb might not be able to achieve a full
5Gb of throughput, but that FlexNIC is allocated half of the NIC's actual throughput.
Requested bandwidth is translated to assigned bandwidth with the following rules:
1. FlexNICs with a "preferred" or "custom" value for requested bandwidth receive their allocated
bandwidth first. For example, if the requested bandwidth setting for the four FlexNICs on a given port
are all 2Gb, then each FlexNIC can be assigned 2Gb of bandwidth.
Requested Allocated
FlexNIC a 2Gb 2Gb
FlexNIC b 2Gb 2Gb
FlexNIC c 2Gb 2Gb
FlexNIC d 2Gb 2Gb
2. After bandwidth is allocated in rule 1 above, FlexNICs with an "Auto" value for the requested
bandwidth divide the remaining bandwidth evenly. For example, if the requested bandwidth setting for
the four FlexNICs on a given port are 1Gb, Auto, Auto, and Auto, then the first FlexNIC is assigned
1Gb (as per rule 1) and the other three FlexNICs divide the remaining 9Gb evenly (3Gb each). There
might be some cases where the bandwidth does not divide evenly because VCM assigns bandwidth in
increments of 100Mb. Connections with a "preferred" setting to a network where no preferred speed
has been defined are treated as a connection set to "auto".
Requested Allocated
FlexNIC a 1Gb 1Gb
FlexNIC b
Auto 3Gb
FlexNIC c Auto 3Gb
FlexNIC d Auto 3Gb
In cases where the requested bandwidth settings you specified for the four FlexNICs in a single physical port
exceed 10Gb, the following rules are applied in this order:
1. If FlexNICs with a "preferred" or "custom" value for requested bandwidth exceed 10Gb, each FlexNIC
is allocated bandwidth proportional to its requested bandwidth setting. For example, if four FlexNICs
on a given port have requested bandwidth settings of 1Gb, 2Gb, 4Gb, and 5Gb, their allocated
bandwidth is as shown in the table below. In this example, 200Mb remains after dividing the 10Gb
link. 100Mb is added to the two connections with the least bandwidth.
