Snapshot XP user guide 35
• Pool Mng. Block used capacity: X GB
Capacity of pool management blocks in use.
CAUTION: The value of Total Capacity in the Pool Information box and the value of Pool Mng.
Block used capacity are approximately equal, but there might be some difference. Even if the value
of Total Capacity in the Pool Information box is updated when pool-VOLs are added to or deleted
from the pool, the value of Pool Mng. Block used capacity is not updated until you click Apply.
NOTE: The capacity of the pool management block in use must be less than its total capacity.
• Pool tree
Pools in the disk array are displayed in a tree format. The following icons appear in the tree.
• Pop-up menu
When you select icons in the Pool tree and right-click, a pop-up menu appears.
• Pool-VOL
Information about pool-VOLs registered in the pool selected in the Pool tree.
• CU:LDEV: Pool-VOL’s CU number and LDEV number
• Capacity: Pool-VOL’s capacity
• Emulation: Pool-VOL’s emulation type
• PG: Parity group to which pool-VOL belongs
• Total Capacity: Total capacity of pool-VOLs in the pool
• Used LDEVs: Total number of pool-VOLs in the pool
• Remaining LDEVs: Total number of pool-VOLs you can add to the pool
• Add Pool-VOL button
Adds selected volumes in the Free LDEVs list as pool-VOLs to the pool selected in the Pool tree.
Icon Description
Disk array or Snapshot XP
Pool in normal status
Blocked pool
Normal pool (in the process of deleting)
Blocked pool (in the process of deleting)
Table 11 Pop-up menu in Pool tree
Command Function
New Pool Opens the New Pool pane ( Figure 10 ). You can select this command only when
you right-click a Snapshot XP icon.
Change Pool Information Opens the Change Pool Information pane ( Figure 11 ). You can select this
command only when you right-click a pool icon.
Delete Pool Deletes the pool. You can select this command only when you right-click a pool
icon.
Restore Pool Restores the blocked pool to the normal status. You can select this command only
when you right-click a blocked pool icon.
