30 Snapshot XP
• Prog./Sync.
Consistency rate of the Snapshot XP pair’s P-VOL and S-VOL. Displayed information changes according
to the pair’s status. See Table 8 .
For more information about what is displayed for Business Copy XP pairs, see the HP StorageWorks
Business Copy XP User Guide for the XP10000/XP12000.
• Type
Volume’s emulation type.
• Capacity(MB)
Volume’s storage capacity in megabytes (MB).
• CLPR(P)
P-VOL’s cache logical partition.
• CLPR(S)
S-VOL’s cache logical partition.
• Pop-up menu
When you select Snapshot XP pair volumes in the volume list and right-click, a pop-up menu appears.
NOTE:
• Grayed out commands are for Business Copy XP pairs. For more information about those
commands, see the HP StorageWorks Business Copy XP User Guide for the
XP10000/XP12000.
• When you select Paircreate or Pairsplit from the pop-up menu, the Paircreate or Pairsplit pane
appears. However, you cannot use these panes to create or split Snapshot XP pairs.
• Volumes X
• X: Total number of volumes in the disk array.
Table 8 Information displayed in Prog./Sync.
Pair status Displayed information
SMPL ---
COPY Consistency rate of the P-VOL and S-VOL in percent (%)
PAIR
COPY(RS)
COPY(RS-R)
PSUS
PSUE ---
SMPL(PD)
Table 9 Pop-up menu in volume list
Command Function
Detail Opens the Detail pane ( Figure 19 ).
Pairsplit-S Opens the Pairsplit-S pane ( Figure 17 ).
S-Vol Path Opens the S-Vol Path pane ( Figure 20 ).
Display Filter Opens the Display Filter pane ( Figure 8 ).
