About SWCC
28
Command Console V2.5 User Guide
Local Serial Port Connection
A local serial port connection uses only the Storage window to manage your
storage subsystems. The client system is connected to the subsystem by a serial
connection, as shown in
Note:
Local serial connections are available only with standalone Storage windows.
You cannot use the Command Console Navigation window to connect locally to a
subsystem.
1
Client system
2
Serial connection
3
Storage system
Figure 2: Local serial port connection
V
T
A
T
O
SHR-1598B
1
2
3
