Page 87
77
Sew Menu
The
Sew
menu allows you to control the way the pattern will be sewn.
■
Sewing Attributes
Purpose:
Sets the sewing attributes for outlines and regions.
Shortcut key:
+
Toolbar:
Operation:
1
Click
Sew
, then
Sewing Attribute
.
In Line Sewing Mode, the
Sewing Attribute Setting
dialog displays the
Line sewing
tab. Here you
can change the settings of the stitch selected in the
Line sew type
selector of the Sewing Attributes
bar. The other stitch settings display in gray.
Sewing Attributes
Sets the sewing attributes for outlines and regions.
Sewing Order
Allows you to check and modify the sewing order of the dif-
ferent colors of a pattern as well as the sewing order of
each color individually.
◆
Enter the desired values for each set-
ting either by clicking on the arrows or
by typing the value directly in the edit
box window.
•
A preview image of the stitch reflects
your setting changes each time you
click on an arrow, except for the
Run
time (s)
setting.
◆
To restore the default value of an indi-
vidual setting, click its
Default
button.
◆
Click the outline(s) you want to apply
the selected settings to.
◆
Click
Close
to exit.
Line sewing attribute
Zigzag stitch
ZigZag width
Sets the width of the zigzag stitch (when
Zigzag Stitch
is selected for the outline).
Range: 1 ~ 10 mm (0.04 ~ 0.39 inch)
Default: 2 mm (0.08 inch)
Density
Sets the number of lines per mm (inch) (when
Zigzag Stitch
is selected for the out-
line).
Range: 1 ~ 7 lines per mm (25 ~ 178 lines per inch)
Default: 4.5 lines per mm (114 lines per inch)
Ctrl
W
