P-touch Template Command Reference
- 62 -
7. Control Command Details
ESC iXR2 Specify line feed command text string
ASCII: ESC i X R 2 n1 n2 data
Decimal: 27 105 88 82 50 n1 n2 data
Hexadecimal: 1B 69 58 52 32 n1 n2 data
Parameters
01h≤n1≤14h
n2: 00h (Fixed)
00h≤data≤FFh
Description
 Specifies the text string for the line feed command.
n1+(n2*256): Length of the text string (can be set between 1 and 20)
data: Text string (The maximum number of characters that can be set is 20 characters
(bytes).)
 The default text string for the line feed command is “^CR”.
 This command is a static command.
Remarks
 Invalid if more than 20 characters have been specified
Example
 To change the text string for the line feed command to “0Dh 0Ah”:
Since the text string to be specified (data), contains 2 characters, n1=02h and n2=00h. Therefore, the
command will be as follows.
ESC i X R 2 02h 00h 0Dh 0Ah
(1Bh 69h 58h 52h 32h 02h 00h 0Dh 0Ah)
