P-touch Template Command Reference

- 50 -

7. Control Command Details

ESC iXT2 Select print start trigger

ASCII:

ESC

i X T 2 n1 n2 n3

Decimal:

27 105 88 84 50 n1 n2 n3

Hexadecimal:

1B 69 58 54 32 n1 n2 n3

Parameters

n1=01h (Fixed)

n2=00h (Fixed)

00h≤n3≤02h

Description



Selects the type of print start trigger.

n3=00h: When the specified text string is received (default)

n3=01h: When all objects are filled

(Prints with the delimiter at the end of the data.)

n3=02h: When the specified number of characters is received

(not including delimiters)



This command is a static command.

Remarks



Invalid if n3 is a value other than 00h through 02h

Example



When the print start trigger is “when all objects are filled”:

ESC i X T 2 01h 00h 01h

(1Bh 69h 58h 54h 32h 01h 00h 01h)
